Infinite power for a better life
?Safety: Highly stable structure cathode material, high-safety electrolyte, safe coating technology;
?High energy density: lightweight structure design, high-voltage electrolyte technology, ultra-thin substrate technology;
?Long life: long-cycle cathode material, uniform electrical and thermal field distribution structure design, long-cycle electrolyte technology;
?Positive structural design for passenger cars.
?Application areas: pure electric vehicles, hybrid electric vehicles, electric vehicles, tourist cars and patrol cars in tourist areas, etc. According to customer requirements, application scenarios, combined with exploring products with the greatest potential value, create the greatest value for customers.
| Model | Material | Capacity (Ah) | Voltage (V) | AC Impedance (mΩ) | Constant Charge Current | Constant Discharge Current | Temperature range (℃) | Cycle requirements 0.5C/1C (100%DOD) | Advantage |
| i50FE | LFP | 50 | 3.2 | ＜1.0 | 1C | 3C | Charge：0~+55℃ Discharge：-20~+60℃ | 2000 | High energy density Long loop；Standard siz |
| i50FL | LFP | 50 | 3.2 | ＜1.5 | 0.8C | 1C | Charge：0~+55℃ Discharge：-20~+60 | 1200 | High energy density Cost-effective；Standard size |
Mass Production of Pouch Cell Module（LFP）
| Product Specification | ||||||
Module | M42 | M48 | M55 | M56 | M57 | |
Cell | i50FL | i50FL | i50FL | i50FE | i50FE | |
Cell Interconnection | 2P18S | 2P12S | 3P12S | 2P18S | 2P10S | |
| Voltage(V) | 57.6 | 38.4 | 38.4 | 57.6 | 32 | |
Capacity(Ah） | 100 | 100 | 150 | 100 | 100 | |
Energy Density(Wh/kg) | 167 | 151 | 167 | 172 | 168 | |
| Cycle Life（0.5C/1C 80%DOD） | 1200 | 1200 | 1200 | 2000 | 2000 | |
| Maximum Discharge Current(A) | 100 | 100 | 150 | 100 | 100 | |
Energy(kWh) | 5.76 | 3.84 | 5.76 | 5.76 | 3.2 | |
Size(mm) | Width(W) | 562 | 382 | 562 | 520.2 | 297.8 |
Depth(D) | 358 | 358 | 358 | 358 | 358 | |
Height(H) | 108 | 108 | 108 | 108 | 108 | |
Weight(kg） | 36.4 | 25.5 | 36.2 | 34.4 | 19.3 | |
Temperature range (℃) | Charge | 0~55 | ||||
Discharge | -20~60 | |||||
